Hey everyone! So, I’ve got something pretty cool to share with you today. It’s the brand-new Rotary Encoder Library for Proteus. A lot of you have been reaching out and asking for it, so I’ve gone ahead and put this library together just for you. Now, adding a rotary encoder to your Proteus projects is a breeze. Let’s take a closer look at how you can make the most out of it in your designs!
Rotary Encoder
A rotary encoder is a device that converts the angular position or rotation of a shaft into digital code. It’s commonly used in various applications such as controlling volume knobs on audio equipment, navigating menus on digital interfaces, or controlling motors in robotics.
Rotary Encoder Proteus Model
Here is the new rotary encoder model I have designed for Proteus, featuring the same interface for connection as the actual hardware. The VCC pin is used to activate the encoder function internally, while the GND pin is utilized for switch functioning. Pin A (CLK) serves as the clock pin, emitting pulses as the encoder rotates, with each pulse denoting a step of rotation, either clockwise or counterclockwise. Pin B (DT) represents data, detecting the direction of rotation.
When pin A emits a pulse, this pin indicates the rotation direction by altering its state. Pin C (SW) is representing the switch (push-button) of the encoder. Upon pressing the button, it connects to the ground GND.
Setting the Encoder Knob Rotation and Speed
When you open up the properties window, you’ll find a couple of options for adjusting your encoder. The first one lets you tweak how quickly the knob spins around—basically, how fast it moves. You can set this speed in Hertz (Hz). The second option is all about which way the knob turns: either clockwise (CW) or counterclockwise (CCW). It’s as simple as picking between 0 for CW or 1 for CCW. So, you have the freedom to control both the speed and direction of your knob’s rotation with ease.
How to use it with Arduino
As we discussed, the connection mirrors that of actual hardware, so you won’t encounter any difficulty interfacing with Arduino. Here’s the Arduino code for reading the encoder.
Simulation
Here is the simulation result of the encoder in the proteus.
Download Library
Simply click on the button to download the library. You can refer to this post for instructions on how to install the library in Proteus 8. How to Download and install Library in Proteus (electronicstree.com)
ZIP Password : electronicstree.com
If you have any requests for Arduino Module Libraries in Proteus, please leave a comment or message us using the contact form.
