Arduino Mega 2560 R3
Hello Proteus Fans, Introducing the new Arduino Mega 2560 R3 Proteus Model. This model is built on the Proteus VSM AVR platform, which supports many Atmel microcontrollers and lets you simulate real-world circuits with ease.
Special attention has been given to ensuring that this Proteus model mirrors the real hardware both in appearance and function. Advanced graphics techniques have been used to capture the board’s layout, detailed component placements, and overall look—providing an authentic simulation experience.
Proteus Model
Arduino Mega 2560 R3 Features
The Arduino Mega 2560 R3 is a powerhouse board designed for projects that require extra connections and higher performance. Powered by the ATmega2560 microcontroller and running at 16 MHz, it offers the speed and reliability needed for complex applications.
One of the key features of the Mega 2560 R3 is its extensive I/O capability. It comes with 54 digital I/O pins, 16 analog inputs, and multiple PWM outputs. This wide array of pins lets you connect many sensors, actuators, and communication modules simultaneously, making it ideal for projects like robotics, home automation, and interactive installations.
In addition, the board is equipped with generous memory: 256 KB of flash memory (with 8 KB reserved for the bootloader) for storing larger programs, 8 KB of SRAM for managing data during execution, and 4 KB of EEPROM for non-volatile storage. This expanded memory capacity means you can run more complex sketches without worrying about running out of space.
Another standout feature is the inclusion of four hardware serial ports. These ports allow for simultaneous communication with multiple devices, simplifying projects that require interfacing with several peripherals or other microcontrollers.
The full documentation for the Arduino Mega 2560 R3 is available on the official documentation page. This resource includes detailed information on installation, configuration, and usage, along with technical specifications and schematics of the board.
Download Library
Simply click on the button to download the library. You can refer to this post for instructions on how to install the library in Proteus 8. How to Download and install Library in Proteus (electronicstree.com)
ZIP Password : electronicstree.com
If you have any requests for Arduino Module Libraries in Proteus, please leave a comment or message us using the contact form.
